|Rated Maximum Power at STC||155W||160W||165W||170W||175W|
|Maximum Power Voltage (Vmp)||18.17V||18.21V||18.25V||18.30V||18.35V|
|Maximum Power Current (Imp)||8.57A||8.80A||9.05A||9.29A||9.54A|
|Open Circuit Voltage ( Voc)||22.53V||22.60V||22.65V||22.72V||22.80V|
|Short Circuit Current (Isc)||8.91A||8.96A||9.01A||9.50A||9.56A|
|Standard Testing Conditions [STC] : Irradiance 1,000W/m², Module Temperature 25°C, Air Mass [AM] 1.5, Certified in accordance with IEC61215, IEC61730-1/2|
|Temperature Coefficient||Mechanical Parameters|
|Normal Operating Cell Temperature||+45°C±2°C||Front (material / thickness)||High Transparency, Low-iron Tempered Glass / 3.2mm|
|Temperature Coefficient of Pmax||-0.41%/°C||Cell (quantity / material / dimensions)||36 ( 4x9 ) / Poly-crystalline Silicon / 156.75x156.75mm|
|Temperature Coefficient of Voc||-0.31%/°C||Encapsulant||EVA Film (Ethylene-Vinyl Acetate)|
|Temperature Coefficient of Isc||+0.06%/°C||Back Sheet (color)||TPT / White or Black|
|Working Conditions||Frame (material / color)||Anodized Aluminum Alloy / Silver or Black|
|Maximum System Voltage||DC 1000V (IEC) / 1500V (IEC) / 600V (UL)||Junction Box / Bypass Diodes||IP67 Rated / 3 or 6 or 9|
|Operating Temperature||-40°C~+85°C||Cable & Connectors||Section Size: 4mm² , Length: 900mm & MC4 compatible|
|Maximum Series Fuse Rating||15A||Module Dimension||1480 x 670 x 30 mm|
|Application Class||Class A||Module Weight||13.20Kg|
|Relative Humidity||0~100% (RH)||Max. Load||Wind Load: 2400Pa / Snow Load: 5400Pa|
We offer all products with high quality and sustainable service to our customers and establishing a long-term cooperative relationship with them.
When can I get the quotation?
We usually quote 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your e-mail so that we will regard your inquiry priority.
How can I get a sample to check your quality
After price confirmation, you can require for samples to check our quality counter display. If you need the samples, we will charge for the sample Express fee. But the cost can be refundable after order confirmation when your quantity of the order is more about the MOQ.
Can you do the design for us?
Yes. We have a professional team having rich experience in design and manufacturing. Just tell us your idea and we will help to carry out your ideas. It does not matter if you do not have someone to complete files. Send us high resolution images, your logo and text and tell us how you would like to arrange them. We will send you finished files for confirmation.
How long can I expect to get the samples?
After you pay the sample charge and send us confirmation files, the samples will be ready for delivery in 3-7 days. You can use your own express account or prepay us if you do not have an account.
What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order. The lead time of MOQ is about 10 to 15 days. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the product at your country.
What is your terms of delivery?
We accept EXW, FOB, C&F and CIF, etc. You can choose the one which is the most convenient or cost effective for you.
